Model | TPS-11 | TPS-15 | TPS-25 | TPS-30 | TPS-39 | TPS-45 | TPS-60 | TPS-100 | ||
Capacity | 5.5KW | 7.5KW | 2KW | 5KW | 8KW | 22KW | 25KW | 32KW | ||
AC Input | 380Vac / 415Vac±20%,Three Phase lnput,50/60Hz±1% | |||||||||
DC Voltage | 36Vdc | 48Vdc | 60Vdc | 7Vdc | 84Vdc | 96Vdc | 120Vdc | 144Vdc | 180Vdc | |
12V 7Ah x3 |
12V 7Ah x4 |
12V 7Ah x5 |
12V 7Ah x6 |
12V 7Ah x7 |
12V 7Ah x8 |
12V 7Ah x10 |
12V 7Ah x12 |
12V 7Ah x15 |
||
Charger Type | Controlled Rectifier CVCC | |||||||||
Charging Time | 10 Hours for 90% of Ful Battery Capacity | |||||||||
Inverter | Technology | IGBT based_PWM Sine Wave | ||||||||
Output Voltage | 380Vac / 415Vac Three Phase 50/60Hz±0.1Hz | |||||||||
Inverter Efficiency | 85% | |||||||||
Overload | 105% continuous | |||||||||
Harmonic Distortion | <3% on Linear load | |||||||||
Crest Factor | 4:1 | |||||||||
Power Factor | 0.8 | |||||||||
PhaseDisplacement | 120°±1° | |||||||||
LCD Display | Start ARD when Black out, Charging Battery. Battery Ful Over Load. Open on level |
|||||||||
Protection | Output Overload & Short Circit, DC Under & Over Voltage |
